| Product Range | ||
|---|---|---|
| Items | Range | Finish |
| S.S Flats | Width : 20 mm To 100 mm | HR |
| Thick : 5 mm to 25 mm | ||
| Weight Chart For Flat Bars | |||
|---|---|---|---|
| Flat (mm) | Kg / m | Flat (mm) | Kg / m |
| 20 x 5 | 0.8 | 40 x 25 | 8 |
| 20 x 8 | 1.28 | 50 x 5 | 2 |
| 20 x 10 | 1.57 | 50 x 6 | 2.4 |
| 20 x 12 | 1.92 | 50 x 8 | 3.2 |
| 20 x 15 | 2.41 | 50 x 10 | 4.01 |
| 30 x 5 | 1.2 | 50 x 12 | 4.8 |
| 30 x 6 | 1.44 | 50 x 15 | 6 |
| 30 x 8 | 1.92 | 50 x 20 | 8 |
| 30 x 10 | 2.41 | 50 x 30 | 12 |
| 30 x 15 | 3.6 | 60 x 6 | 2.88 |
| 30 x 20 | 4.8 | 60 x 8 | 3.84 |
| 40 x 4 | 1.28 | 60 x 10 | 4.8 |
| 40 x 5 | 1.6 | 60 x 12 | 5.76 |
| 40 x 6 | 1.92 | 60 x 15 | 7.21 |
| 40 x 8 | 2.56 | 60 x 20 | 9.6 |
| 40 x 10 | 3.2 | 70 x 8 | 4.48 |
| 40 x 20 | 6.4 | 70 x 10 | 5.6 |
Weight Chart For Angels |
||
|---|---|---|
Size(mm) |
AV. Weight | |
| KG / MTR. | KG / FT | |
| 20 x 20 x 3 | 0.9 | 0.27 |
| 25 x 25 x 3 | 1.1 | 0.34 |
| 25 x 25 x 5 | 1.8 | 0.55 |
| 25 x 25 x 6 | 2.1 | 0.64 |
| 30 x 30 x 3 | 1.4 | 0.43 |
| 30 x 30 x 4 | 1.08 | 0.54 |
| 30 x 30 x 5 | 2.2 | 0.87 |
| 30 x 30 x 6 | 2.5 | 0.77 |
| 35 x 35 x 3 | 1.6 | 0.49 |
| 35 x 35 x 4 | 2.1 | 0.64 |
| 35 x 35 x 5 | 2.6 | 0.79 |
| 38 x 38 x 3 | 1.7 | 0.52 |
| 40 x 40 x 4 | 2.4 | 0.73 |
| 40 x 40 x 5 | 3 | 0.91 |
| 40 x 40 x 6 | 3.5 | 1.07 |
| 50 x 50 x 3 | 2.3 | 0.69 |
| 50 x 50 x 4 | 3 | 0.91 |
| 50 x 50 x 5 | 3.8 | 1.16 |
| 50 x 50 x 6 | 4.5 | 1.37 |
| 65 x 65 x 5 | 4.9 | 1.49 |
| 65 x 65 x 6 | 5.8 | 1.77 |
| 65 x 65 x 8 | 7.7 | 2.35 |
| 65 x 65 x 10 | 9.4 | 2.86 |
| 75 x 75 x 5 | 5.7 | 1.74 |
| 75 x 75 x 6 | 6.8 | 2.07 |
| 75 x 75 x 8 | 8.9 | 2.71 |
| 75 x 75 x 10 | 11 | 3.35 |
| 90 x 90 x 6 | 8.2 | 2.71 |
| 90 x 90 x 8 | 10.8 | 3.29 |
| 100 x 100 x 6 | 9.2 | 2.8 |
| 100 x 100 x 8 | 12.1 | 3.69 |
| 100 x 100 x 10 | 14.9 | 4.54 |
| 100 x 100 x 12 | 17.7 | 5.4 |
